- Parameters
Max Speed：23000r/min
Max RCF：60900xg
Max Capacity：1000mlx4
The max speed is 23000rpm, and Max RCF is 60900g.
It has micro-computer control, electronic lock and AC variable-conversion motor which delivers high torque.
Imported compressor unit with Non-CFC.refrigerant. It measures up to environmental standards.
The machine is programmable. The operation data can be stored automatically.
GL-23M has LCD and LED display. Touching panel makes the operation easy.
The real-time conversation of Speed and RCF is convenient for operation.
It has self-locking device, over-speed safety device, over-temperature safety device, imbalance safety device and automatic alarm device.
It has 10 files of acceleration and deceleration level for your choice.
| Model | GL-23M |
Max speed | 23000r/min |
Max RCF | 60900xg |
Max capacity | 1000mlx4 |
Speed accuracy | ± 50r/min |
Time setting | 1min~99h59min |
Temperature Setting | -20 ～ +40℃ |
Temperature Accuracy | ±1℃ |
Compressor Unit | French Tecumseh Compressor Unit, R404a |
Noise | <65dB(A) |
Power supply | AC110/220V 50Hz/60Hz 30A |
Dimension(LxWxH) | 710mmx840mmx1200mm |
Packing size(LxWxH) | 890mmx960mmx1450mm |
Net weight | 290kg |
 NO.1 Capacity: 1.5/2.2ml×24 Speed: 25000r/min Centrifugal force: 64983×g Adapters：0.2ml、0.5ml  NO.1 Capacity: 5ml×10 Speed: 25000r/min Centrifugal force: 64983×g Adapters：0.5ml、1.5ml  NO.2 Capacity: 10ml×16 Speed: 23000r/min Centrifugal force: 60900×g Adapters：1.5ml、5ml  NO.3 Capacity: 50ml×8 Speed: 18000r/min Centrifugal force: 40930×g Adapters：10ml、20ml  NO.4 Capacity: 250ml×6 Speed: 14000r/min Centrifugal force: 30200×g Adapters：50ml、100ml It is customizable  NO.5 Capacity: 500ml×6 Speed: 10000r/min Centrifugal force: 17800×g Adapters：50ml、100ml、250ml It is customizable  NO.6 Capacity: 1000ml×4 Speed: 7000r/min Centrifugal force: 9980×g Adapters：100ml、250ml、300ml、500ml It is customizable    NO.9 Capacity: Continous Flow Totor1000ml；Speed: 14000r/min Centrifugal force: 21500×g Standard flow：200-600mi/min Material：Stainless steel  NO.10 Capacity: Continous Flow Totor 3000ml；Speed: 8000r/min Centrifugal force: 9500×g Standard flow：200-800mi/min Material：Stainless steel  NO.12 Capacity: Continous Flow Totor 1000ml；Speed: 16000r/min Centrifugal force: 28100×g Standard flow：200-600mi/min Material：Titanium Alloy  NO.13 Capacity: Continous Flow Totor 3000ml；Speed: 10000r/min Centrifugal force: 14800×g Standard flow：200-800mi/minMaterial：Titanium Alloy |
