I. Application Scope
The refrigerator serves for preserving human test samples, medicines, insulin, vaccines, biological products, reagents, etc.
II. Key Indexes
1. Working Temperature Range: 2℃ ~ 8℃ (Ambient temperature: 5℃ ~ 35℃).
2. Available Volume: 536 L.
3. External Dimensions (W × D × H): 900 × 688 × 1950 mm.
4. Internal Dimensions (W × D × H): 820 × 523 × 1375 mm.
5. Net Weight: 155 Kg.
6. Rated Power Input: 340W.
7. Exterior Material: Galvanized steel painted with polyurethane resin powder.
8. Interior Material: Galvanized steel painted with polyurethane resin powder.
9. There is 1 outer door (with 2 double-layer sliding glass door leaves coated with heat-reflecting film and 1 lock).
10. Compressor: Imported Hitachi Compressor.
11. Refrigerant: HC.
12. Standard Configurations: 1 LED lamp, 2 net racks with 2 layers in each, 1 sets of keys and 1 cable for MTR-0621LH.
13. Power Supply (V/Hz): Single-phase source at 220 V/50 Hz.
14. Temperature Control Panel: Digital temperature display.
15. Equipped Casters with locking device.
16. Inspection Hole: 1 hole (with a diameter of 30 mm on the left side).
III. Product Qualification
License for Medical Apparatus and Instrument Manufacturer
Registration Certificate for Medical Device in People’s Republic of China
ISO13485 Medical Device Quality Management System Certification
ISO9001 Quality Management System Certification
ISO14001 Environment Management System Certification
ISO45001 Occupational Health System Certification
IV. Other Parameters
1. The refrigerator is controlled by microcomputer; temperature is displayed digitally; the adjustable increment is 0.1℃;
2. The refrigerator adopts the air cooling system; the temperature fluctuation range inside is ±3℃; the temperature inside can be controlled within the range from 2℃ to 8℃ by adjusting the set temperature;
3. The refrigerator is designed with glass door coated by heat-reflecting film, which can effectively keep external ultraviolet rays and heat away and improve its insulation performance;
4. The refrigerator has multiple fault alarms and can realize high/low temperature alarm, sensor fault alarm, door-opening alarm; there are two alarm modes of buzzer alarm and light flashing alarm;
5. With the locker on the sliding door, ensure the security of samples;
6. The shelf with label tags is convenient for clients to place item labels;
7. The refrigerator is installed with fluorescent lamp for illumination so that reagents inside are clear and conspicuous;
8. The refrigerator is designed with casters to facilitate its mobility and supporting legs for convenient fixing;
9. Condensed water is automatically evaporated after collection so as to avoid the trouble for manual disposal;
10. The refrigerator is designed with a wide voltage scope from 198V to 242V so that it is applicable in areas with unstable voltage.
11. The refrigerator adopts 4 imported famous direct current evaporating fans, forced air cooling cycle, keep the stability of temperature, even if it is overloaded, it can quickly refrigerate; Cyclic defrosting system, even when defrosting, the temperature in the cabinet is still Within the scope of requirements, lower noises compared with other competitor.
